Hydraulic Angle Grinder for Underwater Use
Technical data
Item no.
3030230
Weight without hoses, disc, and guard [kg / lbs]
3.6 / 7.9
Weight without hoses and disc [kg /lbs]
4.2 / 9.2
Weight with hoses, without disc [kg / lbs]
6.4 / 14.1
Blade diameter
Ø230 [mm]
Maximum cutting depth [mm]
80
Oil flow [LPM / GPM]
20-46 / 5-12
Working pressure [bar]
120
Max pressure [bar]
160
Max return pressure [bar / psi]
40 / 580
Rotation speed max [rpm]
4400
Blade peripheral speed max [m/s]
46
Arbor size [Inch]
5/8-11”
Max working depth [m]
50
CE approval
Product Sheet
HAG09 Product sheet
